GoodWe / Lynx A G4 seriesLV batteryLow-voltage battery
Low-voltage battery.16.1 kWh per unit, up to 30 units in parallel.
Energy storage / Residential
Lynx A G4
Low-voltage LFP battery · 16.1 kWh
A 51.2 V lithium iron phosphate battery for low-voltage hybrid and off-grid inverters. Review the specifications and bring your requirements to VOLFAC.
- Rated energy
- 16.1 kWh
- Nominal voltage
- 51.2 V
- Max. output power
- 10 kW
- Ingress protection
- IP65
Share your quantity and delivery destination.
Product overview
16.1 kWh at 51.2 V.
The Lynx A G4 is a low-voltage battery built from 314 Ah LiFePO4 cells, with 16.1 kWh rated and at least 14.9 kWh usable energy. One unit delivers up to 10 kW continuously and 16 kW for 15 seconds; up to 30 units connect in parallel. It mounts on a wall or on the floor, is rated IP65 and discharges from −20 °C to +55 °C. A regulating wheel and aerosol fire extinguishing are options.
- 16.1 kWh, 314 Ah cellsUsable energy of at least 14.9 kWh at 100 % depth of discharge.
- 10 kW output200 A continuous discharge and 16 kW peak for 15 seconds.
- Up to 30 unitsParallel connection of up to 30 batteries.
- IP65Discharging from −20 °C to +55 °C, charging from 0 °C to +55 °C.
Technical specifications
Know the details.
Lynx A G4GoodWeModel Lynx A G4
Brand GoodWeModel Lynx A G4
Performance
- Model
- GW16.1-BAT-LV-G10
- Battery type
- LFP (LiFePO4)
- Rated capacity
- 314 Ah
- Rated energy
- 16.1 kWh
- Usable energy
- ≥ 14.9 kWh (100 % DOD, 0.2 P at 25 ± 2 °C, at the beginning of life)
- Nominal voltage
- 51.2 V
- Voltage range
- 45.92–57.76 V
- Max. continuous charging current (system)
- 157 A
- Max. continuous discharging current (system)
- 200 A
- Max. input power
- 8 kW
- Max. output power
- 10 kW
- Peak output power (system)
- 16 kW for 15 s
- Cycle life
- ≥ 10,000 (laboratory test conditions)
- Scalability
- 30 units in parallel
- Communication
- CAN
Operating conditions
- Charging temperature
- 0 °C to +55 °C
- Discharging temperature
- −20 °C to +55 °C
- Relative humidity
- 5–95 %
- Max. operating altitude
- 4,000 m
- Max. storage time
- ≤ 12 months at −20 °C to +35 °C; ≤ 6 months at +35 °C to +45 °C
- Ingress protection
- IP65
- Protective class
- I
- Mounting
- Wall-mounted or floor-mounted
- Optional functions
- Regulating wheel; aerosol fire extinguishing
Standards
- Safety
- IEC 62619, IEC 60730, IEC 63056, CE
- EMC
- CE
- Transportation
- UN 38.3, MSDS
Dimensions and weight
- Dimensions (W × H × D)
- ≤ 470 × 895 × 245 mm, without base
- Weight
- ≤ 122 kg
Source: GoodWe product pageGoodWe — Lynx A G4 series product page and the Lynx A G4 16 kWh datasheet (EN, V2.1, 22 May 2026).
Downloads
Product documents.
- Technical datasheetLynx A G4 16 kWh · English · PDFLynx A G4, GW16.1-BAT-LV-G10 · English · PDF
- Quick installation guideLynx A G4 16 kWh · Multilingual · PDFLynx A G4, GW16.1-BAT-LV-G10 · Multilingual · PDF
- Certificate IEC 63056Lynx A G4 16 kWh · English · PDFLynx A G4, GW16.1-BAT-LV-G10 · English · PDF
Request a quotation.Share your quantity and delivery destination. We reply with a quotation for Lynx A G4, not an order confirmation.
