ShineWiLan-X2
Wi-Fi and LAN data logger for Growatt devices
A plug-in data logger that connects a Growatt inverter to the monitoring server over Wi-Fi or LAN. Review the specifications and bring your requirements to VOLFAC.
- Data interval
- 5 min
- Interface
- USB
- Protection
- IP65
- Weight
- 94 g
Share your quantity and delivery destination.
Product overview
Monitoring over Wi-Fi or cable.
The ShineWiLan-X2 plugs into the USB port of a Growatt PV or hybrid inverter and sends its data to ShineServer every five minutes, over 2.4 GHz Wi-Fi or a LAN cable. Bluetooth is used for configuration through the app. It keeps up to one month of data in memory and supports local configuration and firmware upgrades.
- WLAN, LAN and Bluetooth802.11 b/g/n at 2.4 GHz, a LAN port and Bluetooth 4.2 in one logger.
- One month of dataBuilt-in memory for up to one month of data.
- USB poweredPowered and connected through the inverter's USB port; 5 V, typically 2.5 W.
- IP65IP65 for −30 °C to +65 °C working temperature.
Technical specifications
Know the details.
ShineWiLan-X2GrowattModel ShineWiLan-X2
Brand GrowattModel ShineWiLan-X2
Wireless
- Wireless standard
- 802.11 b/g/n; BLE 4.2
- Wireless frequency range
- 2.4 GHz
- Transmit power
- 802.11b: 19.5 ± 2 dBm · 802.11g: 14 ± 2 dBm · 802.11n: 18 ± 2 dBm (MCS0), 13 ± 2 dBm (MCS7) · BLE: 0 ± 2 dBm
- Theoretical communication distance
- LAN: 100 m (Cat5e) · Wi-Fi: 50 m without obstruction
Hardware
- Data interface
- USB
- Nominal voltage
- 5 V (± 5 %)
- Typical power consumption
- 2.5 W
- Display
- LED
- Working temperature
- −30 °C to +65 °C
- Storage temperature
- −40 °C to +70 °C
- Protection grade
- IP65
Application
- Supported servers
- ShineServer
- Inverter communication
- Modbus RTU
- Server communication
- MQTT
- Supported networks
- 2.4 GHz Wi-Fi, Bluetooth 4.2
- User configuration
- App
- Data transmission interval
- 5 minutes
- Data memory
- Up to one month
- Compatibility
- Growatt PV devices with a USB port, such as PV and hybrid inverters
General data
- Dimensions (W / H / D)
- 47 / 152 / 28 mm
- Weight
- 94 g
- Certificates
- CE, UKCA, SAA, RoHS
Source: Growatt product pageGrowatt — ShineWiLan-X2 product page and the datasheet (February 2024).
Downloads
Product documents.
- Technical datasheetShineWiLan-X2 · English · PDFShineWiLan-X2 · English · PDF
- User manualShineWiLan-X2 · English · PDFShineWiLan-X2 · English · PDF
- Configuration guideShineWiLan-X2 · English · PDFShineWiLan-X2 · English · PDF
- Certificate of conformity — Radio Equipment DirectiveShineWiLan-X2 · English · PDFShineWiLan-X2 and ShineWiFi-X2 · English · PDF
- Verification of conformity — Low Voltage DirectiveShineWiLan-X2 · English · PDFShineWiLan-X2 and ShineWiFi-X2 · English · PDF
Request a quotation.Share your quantity and delivery destination. We reply with a quotation for ShineWiLan-X2, not an order confirmation.
