Growatt / SPF seriesOff-grid inverterOff-grid solar inverter
Off-grid inverter.6 kW, 48 V battery, two MPP trackers.
Inverters / Off-grid
SPF 6000 ES Plus
Off-grid solar inverter · 6,000 VA / 6,000 W
An off-grid solar inverter for 48 V battery systems with a built-in solar charger and AC charger. Review the specifications and bring your requirements to VOLFAC.
- Rated power
- 6,000 W
- Battery voltage
- 48 V DC
- MPPT trackers
- 2
- Weight
- 13.5 kg
Share your quantity and delivery destination.
Product overview
Solar, battery and AC input in one unit.
The SPF 6000 ES Plus supplies 230 V loads from a 48 V lithium or lead-acid battery, a PV array of up to 8,000 W on two MPP trackers, or an AC source. Grid or solar input priority is configurable, two AC input terminals with an integrated transfer switch are built in, and up to six units can run in parallel.
- Dual MPP trackersTwo independent MPP trackers, 120–450 V DC, 16 A each; PV open-circuit voltage up to 500 V DC.
- 100 A solar chargingSolar charge current up to 100 A and AC charge current of 80 A for a 48 V battery.
- Parallel operationUp to six units in parallel for larger loads.
- Two AC inputsTwo AC input terminals with an integrated transfer switch; transfer time 10 ms typical, 20 ms maximum.
Technical specifications
Know the details.
SPF 6000 ES PlusGrowattModel SPF 6000 ES Plus
Brand GrowattModel SPF 6000 ES Plus
Battery
- Battery voltage
- 48 V DC
- Battery type
- Lithium / lead-acid
Inverter output
- Rated power
- 6,000 VA / 6,000 W
- Parallel capability
- Yes, 6 units maximum
- AC voltage regulation (battery mode)
- 230 V AC ± 5 % at 50 / 60 Hz
- Surge power
- 12,000 VA
- Efficiency (peak)
- 93 %
- Waveform
- Pure sine wave
- Transfer time
- 10 ms typical, 20 ms maximum
Solar charger
- Maximum PV array power
- 8,000 W
- MPPT range at operating voltage
- 120–450 V DC
- Independent MPP trackers / strings per tracker
- 2 / 1
- Max. input current per MPP tracker
- 16 A
- Maximum PV array open-circuit voltage
- 500 V DC
- Maximum solar charge current
- 100 A
AC charger
- Charge current
- 80 A
- AC input voltage
- 230 V AC
- Selectable voltage range
- 170–280 V AC (for personal computers); 90–280 V AC (for home appliances)
- Frequency range
- 50 / 60 Hz (auto sensing)
Physical
- Protection degree
- IP20
- Dimensions (W / H / D)
- 460 / 395 / 132 mm
- Net weight
- 13.5 kg
Operating environment
- Humidity
- 5–95 % relative humidity, non-condensing
- Altitude
- < 2,000 m
- Operating temperature
- 0 °C to 55 °C
- Storage temperature
- −15 °C to 60 °C
Source: Growatt product pageGrowatt — SPF 6000 ES Plus product page and the datasheet (November 2022).
Downloads
Product documents.
- Technical datasheetSPF 6000 ES Plus · English · PDFSPF 6000 ES Plus · English · PDF
- User manualSPF 6000 ES Plus · English · PDFSPF 6000 ES Plus · English · PDF
- CE certificate — Low Voltage DirectiveSPF 6000 ES Plus · English · PDFSPF 6000 ES Plus · English · PDF
- CE certificate — EMCSPF 6000 ES Plus · English · PDFSPF 6000 ES Plus · English · PDF
- Warranty card — off-grid invertersGrowatt off-grid inverters · English · PDFGrowatt off-grid inverters (general card) · English · PDF
Request a quotation.Share your quantity and delivery destination. We reply with a quotation for SPF 6000 ES Plus, not an order confirmation.
